Home > DC Motor > Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine
Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine
Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine
Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine
Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine
1 / 4
Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine
Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine
Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine
Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine

Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine

Send Inquiry

Product Description

Special Promotion
High Power Gear Motor
Motor Range Overview
Product Description
Technical Specifications
Model Rated Voltage(V) No-Load Rated Stall
Operating Range Nominal Speed (RPM) Current (A) Speed (RPM) Current (A) Torque (mN.m) Power (W) Current (A) Torque (mN.m)
RS-550H 23128R 6.0~24.0 24VDC 4500 0.1 3932 0.39 25.7 10.6 4.8 204
6034 6.0~12.0 12VDC 16000 1.12 13613 4.96 25.6 40.36 48.89 281.4
RS-555H 3540 6.0~12.0 12VDC 7800 0.3 6708 1.84 21.9 15.35 11.31 156
23100 6.0~24.0 24VDC 7000 0.14 6004 0.77 19.2 12.09 4.2 124.5
Applications
Motor Applications
Customer Evaluation
Customer Feedback
Certifications
Quality Certification 1
Quality Certification 2
Recommended Products
Recommended Motor Models
Frequently Asked Questions
Are you a trading company or a manufacturer?
We are a factory specializing in micro DC motors and DC gear motors with over 14 years of industry experience.
What are the payment terms for new customers?
We offer multiple payment options including online assurance orders (MasterCard, Visa), PayPal, and TT transfers to ensure a secure transaction.
Can you customize a motor if I can't find a suitable one on your website?
Yes, we provide full customization services to tailor motor specifications according to your specific requirements.
Do your motors come with official certifications?
Yes, our products are certified with CE, FCC, ISO, and other standards. We can also apply for additional certifications if required for your market.
How do you manage quality control?
We employ professional inspectors at every stage of the production line. Final products undergo rigorous testing using advanced equipment such as Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, and Noise Testers.
What is the typical application for these high RPM motors?
These motors are ideal for high-power applications including vacuum cleaners, cordless power tools, and sewing machines where high performance and compact size are essential.
