Strata Motor
Strata Motor
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Voltage (V) | No-Load | Rated | Stall | |||||||
| Range | Nominal | Speed (RPM) | Current (mA) | Speed (RPM) | Current (mA) | Torque (mN.m) | Power (W) | Current (mA) | Torque (mN.m) | ||
| FF-M20VA | 8130 | 2.0-3.0 | 3VDC | 15200 | 45 | 11800 | 160 | 0.16 | 0.19 | 550 | 0.69 |
| 7170 | 1.5-3.0 | 2VDC | 8000 | 25 | 6000 | 75 | 0.09 | 0.06 | 230 | 0.35 | |
| 10100 | 1.5-4.0 | 2.8VDC | 18000 | 50 | 14800 | 190 | 0.2 | 0.3 | 880 | 1.1 | |
Note: Technical parameters can be customized based on requirements.
Established in 2005, we are a high-tech enterprise integrating the research, development, production and sales of various kinds of micro DC motors, geared motors, planetary geared motors, shade pole geared motors and special gearbox motors.
Our products are widely used in automobiles, communications equipment, smart homes, medical equipment, intelligent security, household appliances, kitchen equipment, and other high-end transmission structures. Currently, our products are exported to more than 50 countries and regions worldwide.
We have introduced dozens of advanced production equipment and testing instruments from Germany, Japan, and Switzerland to strictly control the quality of each motor.
